Large Language Models (LLMs) are powerful predictors. Given a sequence of text, they excel at calculating the likelihood of every possible next token (or word) in their vast vocabulary. These likelihoods start as raw scores called logits. But how do we turn a bunch of potential next words into a coherent, creative, and controlled stream of text?

Simply picking the word with the absolute highest logit (greedy decoding) often leads to repetitive and dull output. Also, picking a random word from the vocabulary (naive random sampling) leads to gibberish. We need smarter sampling strategies that introduce controlled randomness, balancing diversity and faithfulness.

This tutorial dives deep into the most common sampling techniques – Temperature Scaling, Top-K Filtering, Top-P (Nucleus) Sampling, and Min-P Filtering. We’ll explore:

  1. How each technique manipulates the logits.
  2. Why each technique is useful (the problem it solves).
  3. How they work together in a specific order.
  4. How to implement and use them with JAX.

Let’s dive in!

🧪 Interactive Demo: Experiment with Sampling Techniques ↗

Imagine our LLM has processed the input "The rocket lifted off towards the" and needs to predict the next word. It outputs logits (raw, unnormalized scores) for its entire vocabulary. Let’s focus on a few plausible candidates (here the logits values are just made up for illustration):

  • moon: logit = 3.5
  • stars: logit = 3.1
  • sky: logit = 2.9
  • station: logit = 2.0
  • launchpad: logit = -0.5 (less likely, but possible)
  • …(thousands of other words with much lower logits)

Our goal is to use sampling techniques to intelligently select one of these words.

1. Adjusting the “Confidence” in other words, Temperature Scaling

  • Why? Raw logits can sometimes be extremely “peaky,” with one token having a vastly higher score than others. This leads back towards greedy, less creative output. Temperature lets us smooth out or sharpen this distribution before filtering.
  • How? We divide every logit by a temperature value.
    • T > 1.0: Decreases the differences between logits, making probabilities more uniform (flatter). Increases randomness, allowing less likely words a better chance. Think of it like turning up the creative chaos.
    • T < 1.0: Increases the differences, making high-probability words even more likely (peakier). Reduces randomness, focusing generation. Think of it like turning down the chaos for more focused output.
    • T = 1.0: No change.

  • Implementation of temperature_scale in JAX:

    # Constants for numerical stability
EPSILON = 1e-9

def temperature_scale(logits: jnp.ndarray, temperature: float) -> jnp.ndarray:
    safe_temperature = max(temperature, EPSILON) # Avoid division by zero
    return logits / safe_temperature

    Simple division, but crucial for reshaping the landscape.

  • Example (Temperature = 0.8):
    • moon: 3.5 / 0.8 = 4.375
    • stars: 3.1 / 0.8 = 3.875
    • sky: 2.9 / 0.8 = 3.625
    • station: 2.0 / 0.8 = 2.5
    • launchpad: -0.5 / 0.8 = -0.625

    Notice the gaps between the top scores are now larger relative to their magnitude, making “moon” even more dominant after this step. If T > 1.0, the opposite would happen.

2. Pruning the long tail, in other words Min-P Filtering

  • Why? Sometimes, even after temperature scaling, there are many tokens with non-negligible but still very low probabilities compared to the best option. Min-P offers a dynamic way to filter these out based on the peak probability in the current distribution. It helps remove the long tail without needing a fixed k or p.
  • How?
    1. Calculate the probability of each token using softmax on the (potentially temperature-scaled) logits.
    2. Find the maximum probability (max_prob).
    3. Set a threshold: min_threshold = max_prob * min_p.
    4. Discard (set logits to -inf) any token whose probability is less than min_threshold, unless it’s one of the tokens that had the max_prob (to ensure we always keep the most likely option).

  • JAX Implementation (min_p_logits):

    def min_p_logits(logits: jnp.ndarray, p: float) -> jnp.ndarray:
    probs = nnx.softmax(logits, axis=-1) # Convert current logits to probs
    max_prob = jnp.max(probs, axis=-1, keepdims=True)
    threshold = max_prob * p

    # Identify indices corresponding to max probability
    max_prob_indices = probs >= (max_prob - EPSILON)

    # Keep max prob tokens and tokens above the threshold
    mask_below_threshold = probs < threshold
    # Mask is True for tokens we want to discard
    mask = jnp.where(max_prob_indices, False, mask_below_threshold)

    # Apply the mask (set discarded logits to -inf)
    return jnp.where(mask, -jnp.inf, logits)
  • Example (Continuing with T=0.8 logits, Min-P = 0.1):
    1. Softmax: Convert [4.375, 3.875, 3.625, 2.5, -0.625, ...] to probabilities. Let’s approximate: exp(4.375) ≈ 79.4, exp(3.875) ≈ 48.2, exp(3.625) ≈ 37.5, exp(2.5) ≈ 12.2, exp(-0.625) ≈ 0.5. Sum ≈ 177.8 (just for these 5).
      • Prob(moon) ≈ 79.4 / 177.8 ≈ 0.447 (This is max_prob)
      • Prob(stars) ≈ 48.2 / 177.8 ≈ 0.271
      • Prob(sky) ≈ 37.5 / 177.8 ≈ 0.211
      • Prob(station) ≈ 12.2 / 177.8 ≈ 0.069
      • Prob(launchpad) ≈ 0.5 / 177.8 ≈ 0.003
    2. Threshold: min_threshold = 0.447 * 0.1 = 0.0447
    3. Filter:
      • Keep moon (prob 0.447 >= 0.0447) -> logit remains 4.375
      • Keep stars (prob 0.271 >= 0.0447) -> logit remains 3.875
      • Keep sky (prob 0.211 >= 0.0447) -> logit remains 3.625
      • Keep station (prob 0.069 >= 0.0447) -> logit remains 2.5
      • Discard launchpad (prob 0.003 < 0.0447) -> logit becomes -inf * Our logits are now: [4.375, 3.875, 3.625, 2.5, -inf, ...]

3. Top-K Filtering or The VIP List

  • Why? To impose a hard limit on the number of choices, regardless of their probabilities. This prevents the model from considering truly bizarre (but maybe slightly probable after temperature/min-p) tokens. It ensures a minimum level of focus.
  • How? Simply select the k tokens with the highest current logits and discard all others by setting their logits to -inf.

  • JAX Implementation (top_k_logits):

    def top_k_logits(logits: jnp.ndarray, k: int) -> jnp.ndarray:
    # ... (error checks, handle k > vocab_size) ...
    k = min(k, logits.shape[-1])

    # Efficiently find the value of the k-th largest logit
    top_k_values = jax.lax.top_k(logits, k=k)[0] # Gets values, not indices
    kth_value = top_k_values[..., -1:] # The smallest value in the top-k set

    # Create a mask: True for logits >= k-th value
    mask = logits >= kth_value

    # Apply mask: Keep top-k, set others to -inf
    return jnp.where(mask, logits, -jnp.inf)

    jax.lax.top_k is efficient for finding the threshold value.

  • Example (Continuing, Top-K = 3):
    • Current logits: [4.375, 3.875, 3.625, 2.5, -inf, ...]
    • The top 3 logits are 4.375 (moon), 3.875 (stars), 3.625 (sky).
    • The 3rd highest logit is 3.625.
    • Filter:
      • Keep moon (4.375 >= 3.625) -> logit 4.375
      • Keep stars (3.875 >= 3.625) -> logit 3.875
      • Keep sky (3.625 >= 3.625) -> logit 3.625
      • Discard station (2.5 < 3.625) -> logit becomes -inf
      • launchpad remains -inf.
    • Our logits are now: [4.375, 3.875, 3.625, -inf, -inf, ...]

4. Top-P (Nucleus) Filtering: The Probability Budget

  • Why? Top-K uses a fixed number (k), but sometimes the probability distribution is very sharp (only 1-2 good options), and sometimes it’s flat (many decent options). Top-P adapts dynamically. It selects the smallest set of tokens whose cumulative probability mass exceeds a threshold p. This captures the “nucleus” of likely candidates.
  • How?
    1. Convert the current logits (after Temp, Min-P, Top-K) into probabilities using softmax.
    2. Sort these probabilities in descending order.
    3. Calculate the cumulative sum of the sorted probabilities.
    4. Find the tokens whose cumulative probability is <= p. Crucially, always include at least the highest probability token.
    5. Discard all other tokens by setting their original logits (from the input to this function) to -inf.

  • JAX Implementation (top_p_logits):

    def top_p_logits(logits: jnp.ndarray, p: float) -> jnp.ndarray:
    # ... (error checks, handle p=1) ...
    probs = nnx.softmax(logits, axis=-1) # Probs from current logits

    # Sort probabilities DESCENDING
    sorted_probs = jnp.sort(probs, axis=-1)[..., ::-1]
    # Get corresponding indices (needed to map back later, though not explicit here)
    # sorted_indices = jnp.argsort(probs, axis=-1)[..., ::-1]

    cumulative_probs = jnp.cumsum(sorted_probs, axis=-1)

    # Create a mask on the *sorted* probabilities
    sorted_mask = cumulative_probs <= p
    # Ensure the top-1 token is always included
    sorted_mask = sorted_mask.at[..., 0].set(True)

    # Find the minimum probability value *within* the nucleus (in the sorted list)
    threshold = jnp.min(
        jnp.where(sorted_mask, sorted_probs, jnp.ones_like(sorted_probs)), axis=-1, keepdims=True
    )

    # Apply this threshold to the *original* probability distribution
    mask = probs >= threshold

    # Apply the final mask to the *input logits*
    return jnp.where(mask, logits, -jnp.inf)

    This implementation cleverly finds the probability threshold from the sorted list and applies it back to the original probabilities to create the final mask.

  • Example (Continuing, Top-P = 0.7):
    1. Softmax on current logits: [4.375, 3.875, 3.625, -inf, -inf, ...]. exp(4.375) ≈ 79.4, exp(3.875) ≈ 48.2, exp(3.625) ≈ 37.5. Others are 0. Sum ≈ 165.1.
      • Prob(moon) ≈ 79.4 / 165.1 ≈ 0.481
      • Prob(stars) ≈ 48.2 / 165.1 ≈ 0.292
      • Prob(sky) ≈ 37.5 / 165.1 ≈ 0.227
    2. Sort & Cumulate:
      • Sorted Probs: [0.481 (moon), 0.292 (stars), 0.227 (sky)]
      • Cumulative Probs: [0.481, 0.773, 1.0]
    3. Filter (p=0.7):
      • Keep moon (cumulative 0.481 <= 0.7).
      • Stop: stars (cumulative 0.773 > 0.7). We only keep the tokens before crossing the threshold p, but always ensure the first one is kept. In this case, only “moon” makes the cut based on cumulative_probs <= p.
    4. Final Logits: Apply the mask to the logits we fed into this step: [4.375, -inf, -inf, -inf, -inf, ...].

Orchestrating the Sampling: The sample_logits Function

This function brings everything together. It defines the order of operations, which is crucial.

def sample_logits(
    logits: jnp.ndarray,
    rng_key: jax.Array,
    temperature: float = 1.0,
    top_k: int | None = None,
    top_p: float | None = None,
    min_p: float | None = None,
    do_sample: bool = True,
) -> jnp.ndarray:
    if not do_sample: # Handle greedy decoding
        return jnp.argmax(logits, axis=-1)

    # 1. Apply temperature scaling
    scaled_logits = temperature_scale(logits, temperature) # Use safe scaling

    logits_for_fallback = scaled_logits # Store for safety

    # 2. Apply filtering (Order: Min-P -> Top-K -> Top-P)
    filtered_logits = scaled_logits
    if min_p is not None and 0 < min_p < 1.0:
        filtered_logits = min_p_logits(filtered_logits, min_p)
    if top_k is not None and top_k > 0:
        filtered_logits = top_k_logits(filtered_logits, top_k)
    if top_p is not None and 0 < top_p < 1.0:
        filtered_logits = top_p_logits(filtered_logits, top_p)

    # 3. Handle edge case: If all logits became -inf (over-filtering)
    all_filtered_infinite = jnp.all(filtered_logits == -jnp.inf, axis=-1, keepdims=True)
    # Fallback to the pre-filtering (but post-temperature) logits if needed
    final_logits_for_sampling = jnp.where(
        all_filtered_infinite,
        logits_for_fallback,
        filtered_logits,
    )

    # 4. Sample from the final distribution
    sampled_indices = jax.random.categorical(rng_key, final_logits_for_sampling, axis=-1)

    return sampled_indices

Key Takeaways:

  1. Order: Temperature -> Min-P -> Top-K -> Top-P. This specific order applies the broad temperature adjustment first, then prunes the dynamic low-end (Min-P), then enforces a hard count limit (Top-K), and finally applies the dynamic probability mass limit (Top-P). Other orderings are possible but would yield different results.
  2. Fallback: It includes crucial logic (jnp.where(all_filtered_infinite, ...)) to prevent errors if the combination of filters accidentally removes all possible tokens. In that rare case, it falls back to sampling from the distribution after temperature scaling but before any filtering.
  3. Final Sampling: jax.random.categorical performs the actual sampling. It takes the final, filtered logits, implicitly converts them to probabilities via softmax (since categorical works on logits), and draws a sample according to those probabilities using the provided JAX rng_key.
  4. Greedy Option: If do_sample=False, it bypasses all sampling logic and simply returns the index of the highest original logit (jnp.argmax).

Putting it into Practice: Autoregressive Generation

The GenerationMixin class wraps this logic into a usable generation loop.

class GenerationMixin:
    # Core logic using lax.scan
    def _generate_scan_logic(self, ...):
        # ... setup initial state (output_ids, rng, finished flags) ...

        def scan_step(carry, _):
            # ... get current state ...
            # Call the model (self) to get logits for the *next* token
            logits = self(input_ids=current_output_ids, ...)
            next_token_logits = logits[:, current_length - 1, :] # Get the logits for the token we need to predict

            # *** THE KEY CALL ***
            next_token = sample_logits(
                logits=next_token_logits,
                rng_key=sampling_rng,
                temperature=temperature,
                top_k=top_k,
                top_p=top_p,
                min_p=min_p,
                do_sample=do_sample
            )

            # ... update output_ids, finished flags, rng, length ...
            return next_carry, None

        # ... run jax.lax.scan ...
        final_output_ids = # result of scan
        return final_output_ids

    # Jitted version (using partial for static args)
    _generate_compiled = partial(jax.jit, static_argnames=(...))(_generate_scan_logic)

    # Public API method
    def generate(self, input_ids, ..., use_jit=False):
        # ... input validation, handle RNG, resolve pad/eos tokens ...

        # Decide whether to call the raw Python loop or the JIT-compiled one
        if use_jit:
            final_output_ids = self._generate_compiled(...)
        else:
            final_output_ids = self._generate_scan_logic(...)

        return final_output_ids

You can find the full code here.

Key Aspects of GenerationMixin:

  1. Autoregression: It works step-by-step. In each step (scan_step), it calls the underlying LLM (self(...)) with the current sequence to get logits for the next token.
  2. lax.scan: This JAX primitive is used for efficient looping on accelerators (GPU/TPU). It compiles the scan_step function and executes it repeatedly.
  3. Integration: It seamlessly integrates the sample_logits function, feeding it the relevant logits and sampling parameters at each step.
  4. State Management: It handles updating the generated sequence (output_ids), managing the JAX PRNG key (rng), tracking finished sequences (finished), and padding.
  5. JIT Compilation: It provides an option (use_jit=True) to call a jax.jit-compiled version (_generate_compiled) of the generation loop. This significantly speeds up generation by compiling the Python logic into optimized XLA code, but requires parameters like temperature, top_k, top_p, min_p, do_sample, max_length etc., to be static (known at compile time).

Conclusion: Your Control Panel for AI Creativity

You now have a deep understanding of how Temperature, Min-P, Top-K, and Top-P sampling work together to shape the output of language models within a JAX framework.

  • Temperature: Controls the overall randomness/conservatism.
  • Min-P: Dynamically removes the lowest probability tail based on the peak.
  • Top-K: Enforces a hard limit on the number of candidates.
  • Top-P: Enforces a dynamic limit based on cumulative probability mass.

The sample_logits function orchestrates these steps in a specific order, and the GenerationMixin integrates this into an efficient, JIT-compilable autoregressive loop. By mastering these parameters, you gain control over your LLM’s voice, balancing focus and creativity. Experiment with these tools to unlock new possibilities!
